General
Box quantity
1
GTIN-13 / EAN
5056009589522
Colour
white
Fault current protection (RCD)
30mA
Individual unit weight (g)
138
Width mm
19
Height mm
90
Depth mm
75
Size/Dimensions (mm)
19X90X75
Surf area M^2
0.020
Technical
Bidirectional
Yes
Protected poles
1
Switched poles
2
Associated standards
BS EN 61009
Rated voltage
220-250V
Rated kA
10
Rated current
40A
Frequency
50-60Hz
Wiring system
2 pole
Width in number of modular spacings
1
Nature of supply
AC
Rated fault current
30mA
Release characteristic
B
Mounting method
DIN Rail
